TECHNOSCOPE F17 (5m)

Throughout the history of cinema, the telescopic camera crane has been the foundation of some of the most stunning long takes and complex camera movements. The Filmotechnic Technoscope is a new series of ultra-lightweight and compact telescopic camera cranes, which are easy to deliver, assemble and operate in hard-to-reach places.

The Technoscope’s smooth and quiet operation makes it perfect for indoor use. The Mitchell mount allows the telescopic boom to be mounted on any camera dolly or any other Mitchell mount platform. The crane can be powered by either battery or a 110V/220V power supply.

The Technoscope is the perfect crane to work with any lightweight remote head, making this technology more accessible than ever before.

  • User-friendly interface
  • Lightweight portable elements
  • Long-lasting battery autonomy
  • Compact in size and small footprint
  • Assembled and ready for camera in less than 30′
  • Stable base with pneumatic or track wheels
  • Durable and state of the art carbon fiber design
  • Arc compensation with our so-called ‘Wall Mode’
  • Telescoping hand control unit
  • Comes standard with Raincover
  • Adapter for Ronin and MōVI
  • Battery-powered
  • Optional Electronic Nose Suspension

TECHNOSCOPE F17 - SPECIFICATIONS

Total Weight Crane 102.8kg / 227lbs
Base Weight 24kg / 53lbs
Leveling Jacks Weight 4.8kg / 10.5lbs
Tripod Weight 24kg / 53lbs
Arm Weight 50kg / 110lbs
Max Nose Load 25kg / 55lbs

16 Counter Weights of 9kg / 19.8lbs
6 Counter Weights of 7.6kg / 16.7lbs
2 Counter Weights of 4.5kg / 9.9lbs
4 Counter Weights of 2.6kg / 5.7lbs
2 Side Trim Weights of 1.3kg / 2.8lbs

Telescoping Range 3.9m / 12′ 10″
Telescoping Speed 2m/sec
Min. Door Height 1.54m / 5′
Max Lens Height 5m / 16′ 5″
Operating Temp -20˚C to +40˚C

POWER REQUIREMENTS
36-60 VDC
